About Jakosmart
Jakosmart serves global electronics customers specializing in PCB, IC packaging substrates and PCBA solutions.
Our PCB portfolio covers multilayer, HDI and heavy copper boards. For IC packaging substrates, we deliver BT and ABF material constructions tailored for memory, sensor, MEMS, RF and flip-chip packaging applications. Our PCBA offering encompasses board assembly, component procurement and full-range testing services.
We have strategically invested in manufacturing facilities across China and Southeast Asia to reliably accommodate variable customer requirements. Powered by robust R&D capabilities, our team manages customer specification alignment, engineering validation, production resource allocation, sample development and mass delivery. We support customers with standalone product projects or integrated one-stop sourcing for PCB and assembly.
From bare printed circuit boards and chip packaging substrates to finished assembled boards, we bridge design intent with manufacturing execution, matching your unique requirements on product specifications, volume and lead time.


Quality is our culture
Advanced engineering expertise and technical support are our strengths.
Customized solutions are our specialty.
Cost-effective manufacturing and rigorous supply chain control are our advantages.
Total customer satisfaction is our goal.
